THS42 compression probes

Druckstößel



Description: pdf_icon.gifTHS42 Datasheet.pdf

Description: pdf_icon.gifTHS42 Datenblatt.pdf

Description: THS42-R5-41-Af159-Nivermutlich EN13892-6-

THS42-R5-40-Af159



Compression probe with radius 5 mm, pin length 41 mm, Af15.9 mm

Description: THS42-R1

THS42-R1.5-70-Af159



Compression probe with radius 1.5 mm, pin length 70 mm, Af15.9 mm

Description: THS42-KR2

THS42-K5-74-Af159



Compression probe with a ball

Ball diameter 5 mm, pin length 74 mm, Af15.9 mm

Description: THS42-K9

THS42-K9.52-80-Am22



Compression probe with a ball

Ball diameter 9.52 mm, pin length 80 mm, Am22 mm

Description: THS42-M4-D10 -Druckstoessel-austauschbare-Spitze-

THS42-M4-D10



Compression probe with an interchangeable ball

Inner thread M4, ball diameter 10 mm

THS42-D12-8.55-V90-L79-Af159

Special compression probe, diameter 12 mm, length 79 mm

Coupling Af159



Description: tn_THS42-R16.5-Am5025-

THS42-R16.5-AM5025

Description: THS42-100-47-Af159

THS42-R50-50-Af159



Hemispherical compression probe

Radius 50 mm, probe height 50 mm

THS42-D50-Af3816



Special compression probe, diameter 50 mm,

Coupling Af38, weight 1,8 kg



Description: THS42-180-55-M10-

THS42-R90-40-M10



Hemispherical compression probe

Radius 90 mm, probe height 40 mm
